ALL MANUFACTURERS

DIGITIZING INTERFACE BOARD

PC BOARD
DIGITIZING INTERFACE BOARD
(502-02777-50)
Analog to Digital Conversion: 4-20mA, 0-10V
4-20mA current loop inputs.
0-10V or 0-5V voltage inputs.
Operating Temperature: -20°C to +70°C
Storage Temperature: -40°C to +85°C.
Humidity: 5% to 95% non-condensing.

Controller drive

Nominal Bus Output Voltage 300V DC
Continuous Current(RMS) 45.0 A
Peak Current(RMS) 90.0 A
Continuous Power Output 15.0 kW
Peak Power Output 30.0 kW
Input Circuit Breaker Rating 38A RMS
Circuit Breaker Interrupt Rating 1300 A
Static Gain 1.5x Rated Motor I/RPM

Discrete input module

Input voltage 0 to +30VDC,+24VDC nominal
On state voltage +15 to +30VDC
Off state voltage 0 to +5VDC
Off state current 2.0 to 5.5mA0 to 0.5mA
Off response time 0.5ms maximum
Configurable filtertime0 ms, 1.0ms (default), or 7.0ms
Input impedance 10kOhms maximum

I/O EXPANSION UNIT

CONTROL WAVE
BASE CHASSIS
MICRO PANEL
8 SLOT
2 MA AT 3.3 VDC
RACK MOUNT

DC Power Supplies

Universal AC Power
High Voltage DC Power Supply
Low Voltage DC Power Supply
Inputvoltage 20 to 30 Vdc
Highvoltage DC 2.5 A (maximum)

Micronet Ethernet Module

Series: MicroNet Digital Controllers
Flash Memory: 64 MB
Input Voltage: 110 VAC/125 VDC
Features: 10/100 Base T Ethernet
Maximum Stub Length: 300 mm
Dimensions: 9.50 x 10.50 x 1.00
Model: 10BaseT Ethernet Connector
Potential Voltage Range: 80-150

Central processing unit

SIMATIC S7-1500
CPU 1517-3 PN/DP
Central processing unit
with work memory2 MB for
Program and 8 MB for data
1st interface: PROFINET IRT with 2-portswitch
2nd interface: PROFINET RT
3rd interface: PROFIBUS
2 ns bitperformance
SIMATIC Memory Card required

System bundle

SIMATIC S7-400H
412-5H system bundle H-system
with 1 x UR2-H, withoutmemory card
2 x PS407 UC120/230V
10 A, 4 x sync modules up to 10 m
2 xsync cables 1 m
2 x CPU 412-5H
in addition 2 memory cards and
4 backupbatteries required

Micro Memory Card

SIMATIC S7
Micro Memory Card
for S7-300/C7/ET 200
3, 3V Nflash
64 KB

Board

4 x 0-10V or 4-20mA inputs
High precision A/D conversion
for accurate measurements of pressure
flow, and other hydraulic parameters
4 x 0-10V or 4-20mA outputs
Sampling Rate: 1 kHz
Resolution: 12-bit or 16-bit resolution for analog I/O
Precision: ±0.1% full scale

Switching Power Supplies

Product: Switching Supplies
Output Voltage-Channel 1: 5 VDC
Output Voltage-Channel 2: -
Number of Outputs: 1 Output
Output Power: 40 W
Open Frame/Enclosed: Open Frame
Input Voltage: 90 VAC to 264 VAC
Output Current-Channel 1: 8 A
Efficiency: 70 %

INTERFACE CARD

4 x 0-10V or 4-20mA inputs
High precision A/D conversion
for accurate measurements of pressure
flow, and other hydraulic parameters
4 x 0-10V or 4-20mA outputs
Sampling Rate: 1 kHz
Resolution: 12-bit or 16-bit resolution for analog I/O
Precision: ±0.1% full scale

Termination assembly

32 channel
voltage monitor132 V AC or 150 V DC
maximumLogic Zero - 0 to 20 V AC; 0to 20 V DC
Logic One - 80 to 132 V AC;75 to 150 V DC
Input Current for Logic One;2.6 mA
maximumChannel isolation provided by
termination assembly

TERMINATION ASSEMBLY

VOLTAGE MONITOR TERMINATION ASSEMBLY
SCREW TERMINAL
EXTERNAL SWITCH
CABLE TYPE 4
FBM 241 125V
VMON, +5A
RELAY OUT
P/N - P0916AS

System Rack

01 19-inch Rack (14 module slots)
02 Rack Mount Option, Full-Size Rack
(mounts to19-inch EIA Rack)
01 CSA/NRTL/C (Class 1, Division 2)
00 None
01 CE
The 3500/05 mini-rack is not available
in theBulkhead Mount option.

Ethernet/RS232 Modbus I/O Module

Accepts from 1 to 16 signals
Input impedance: Greater than 1 MΩ
Power consumption: 3 watts
Front panel LEDs: OK, TX/RX, Bypass
Type E, J, K, T thermocouples
100 Ω 3-wire and 4-wire platinum RTD

Analog Input/Output Module

8 channels AIO208, 16 channels AIO216
Analog inputs and outputs
Filter adjustable from 4 kHz to 0.5 Hz per channel
All outputs overload, short circuit and external voltage-proof
Measuring range monitoring freely adjustable (±105 %)
Error message on overload and overtemperature and undervoltage of the supply
Galvanic isolation from the system 500 V
Modes that can be selected per channel:
Analog voltage input ±10 V to ±10 mV
Analog current input 0(4) to 20 mA

Protection System

Monitoring of Sensors
Monitoring versus Low speed as
protection versus incorrect mounting
or fault of speedsensors.
Monitoring versus overspeed

4-Channel Relay Module

Power Consumption:6 watts typical.
Environmental Sealing:Epoxy-sealed
Arc Suppressor: 250 Vrms, installed as standar
Contact Life:100,000 cycles @ 5 A, 24 Vdc or120 Vac

System Display

Local or Remote Visual Indication
of 3500 Machinery Protection System
(4) Display Mounting Types
Up to (2) Displays per 3500 Rack
Input Signal: -10 Vdc to +10 Vdc
Power Consumption: 10.5 watts
Ethernet: 100Base-FX Fiber-Optic

Rack Interface Module

Power Consumption:4.75 watts, typical
Standard:RS232 serial communications
Data Rate:38.4 k baud
Normally closed contacts:Arc suppressors are provided
Maximum Current:<1 mA dc, Dry Contact to Common

Proximitor Monitor

Signal :Accepts from 1 to 4 proximitytransducer signals
Power consumption :7.7 Watts, typical
Standard I/O: 10 kΩ
Output Impedance:550 Ω
Transducer Power Supply:-24 Vdc
Gap filter:-3 dB at 0.09 Hz
Smax : 0.125 to 15.8 times runningspeed

VGA Display Monitor

System Event List
Alarm Event List
All module and channel data
3300 style rack view (API-670)
Current alarm data (quick view)
Nine custom display options

Proximitor I/O Module with Internal Terminations

(4) Channel Monitor
Internal terminations
Dual-level alarms (Alert/Danger)
Dynamic and static measurement
Various "Static Value" Parameters
Accepts Input from Proximity Transducers
Proximitor I/O Module with Internal Terminations

Vibration Transmitter

7 0 7.0 metres (23.0 feet)
0 2 Bulkhead screws
0 1 CSA Division 2
Power : Requires +12 to +35 Vdc
input at the transmitter terminal.
Maximum Loop Resistance :
1,000 Ω including cable at 35 Vdc.
Current Limiting : 23 mA typical.
