ALL MANUFACTURERS

FILTER

Rated Voltage: 250V AC
Current Rating: 5A (continuous)
Frequency Range: 50/60Hz
Filter Type: π-type (C-L-C) filter
Common Mode Attenuation: >60dB @ 1MHz
Differential Mode Attenuation: >40dB @ 100kHz

Cross Profile

Cross Profile
62mm W,
1m L For Use With TriLine

Industrial module

Channels:8/16 DI or DO
Input Voltage:24V DC
Output Type:Relay/Transistor
Isolation:1.5kV AC
PROFIBUS DP (via coupler)
Modbus RTU (RS-485)
EtherNet/IP (optional)

Control Board

Operating Voltage: 24V DC (±10%)
Power Consumption: <5W typical
Isolation Voltage: 1500V AC
Analog Inputs:2 channels
Digital Inputs:24V DC, optically isolated
Relay Outputs:250V AC/30V DC, 2A
PROFIBUS DP
Modbus RTU
DeviceNet

Control Module

Input Channels: 4
Voltage: ±10V, ±5V, 0-10V, 0-5V
Current: 0-20mA, 4-20mA (with HART support)
Resistance: RTD (Pt100, Pt1000)
Thermocouple: J, K, T, E, N, R, S, B
Resolution: 16-bit (0.0015% of range)
Accuracy: ±0.05% of span (typical)
Update Rate: 50ms per channel (all channels)
Common Mode Rejection: >120dB @ 50/60Hz

Control Circuit Board

Operating Voltage: 24V DC ±10%
Power Consumption: <8W typical
Isolation Voltage: 2000V AC
Analog Inputs:0-10V/±10V/4-20mA configurable
Digital Inputs:24V DC, optically isolated
Relay Outputs:250V AC/30V DC, 5A
PROFIBUS DP
CANopen
Modbus RTU

Control Circuit Board

Power Consumption:6W typical
Isolation Voltage:2000V AC (input to output)
Analog Inputs:2 channels (0-10V/4-20mA)
Digital Inputs:6 channels (24V DC)
Relay Outputs:3 channels (250V AC/5A)
Resolution: 14-bit (analog inputs)
Sampling Rate: 10kHz (control loop)
Response Time: <2ms (digital I/O)
Accuracy: ±0.1% of full scale

Control Circuit Board

Operating Voltage: 24V DC ±10%
Power Consumption: 10W typical
Isolation Voltage: 2500V AC (input to output)
Processor: 32-bit DSP + FPGA
Control Loop Update: 62.5μs
Analog Inputs:2 channels (±10V/4-20mA)
Digital Inputs:8 channels (24V DC)
Relay Outputs:3 channels (250V AC/2A)
Encoder Interface:1 channel (HTL/TTL/SSI)

Controller Card

Processor:Dual-core ARM Cortex + FPGA
Clock Speed:800 MHz (ARM), 200 MHz (FPGA)
Memory:512 MB DDR3 RAM
Operating Voltage:24V DC ±10%
Power Consumption:5W (max)
Isolation :2500V AC
Analog Inputs:4 ch (16-bit, ±10V/4-20mA)
Digital Inputs:12 ch (24V DC, 3ms debounce)
Relay Outputs:4 ch (250V AC/5A)
Encoder:2 ch (HTL/TTL/SSI/EnDat 2.2)

Controller Card

Operating Voltage: 24V DC ±10%
Power Consumption: 18W
Control Loop Speed: 31.25μs
Positioning Accuracy: ±1 encoder count
Velocity Ripple: <0.01% of rated speed
Synchronization Jitter: <100ns between axes
Analog Inputs:6 ch (16-bit, ±10V/4-20mA, 50kHz)
Digital Inputs:16 ch (24V DC, <100μs response)
Relay Outputs:6 ch (250V AC/5A, 30V DC/5A)
Encoder Inputs:3 ch (Differential RS422, 20MHz)
PTC/KTY Inputs:4 ch (Motor temp sensors)

CPU 1515F-2 PN Processor Module

Single Motor Module

SINAMICS S120
Single Motor Module
input: 600 V DC
output: 400 V 3AC, 60 A
type of construction: booksize internal
air cooling optimized pulse patterns and support
of the extended Safety Integrated functions
including DRIVE-CLiQ cable

Single Motor Module

SINAMICS S120
Single Motor Module
input: 600 V DC
output: 400 V 3 AC,
18 A type of construction:
booksize internal air cooling optimized
pulse patterns and support of the extended
Safety Integrated functions
incl. DRIVE-CLiQ cable

PC BOARD

PC BOARD
PWA SMI
16 MHZ SENSOR
PWA, SENSOR MICRO-101

LOGO! USB PC Cable

IGBT Module

Collector-Emitter Voltage (Vces):1200V
Collector Current (Ic @ 25°C):450A
Collector Current (Ic @ 80°C):300A
Pulse Current (Icm):900A
Power Dissipation (Ptot):1800W
Gate-Emitter Voltage (Vges):±20V
Turn-on Delay Time (tdon):110ns
Rise Time (tr):50ns
Turn-off Delay Time (tdoff):400ns
Fall Time (tf):120ns
Switching Frequency:Up to 20kHz

Control Interface Module (CIM)

Supply Voltage: 24 V DC nominal
Power Consumption: Approximately 5–10 W
Isolation Voltage: 500 V AC
Digital Inputs: Voltage range 24 V DC
Digital Outputs:24 V DC
Analog Inputs: Voltage (±10 V）

Control Unit

3300 XL 8 mm Reverse Mount Probes

Total length option : 10 = 1.0 metre (3.3 feet)
Connector option : 02 = Miniature ClickLocTM coaxial connector
Agency approval option : 00 = Not required
Probe tip material : Polyphenylene sulfide (PPS).
Probe case material : AISI 303 or 304 stainless steel (SST).
