Profibus OLM/G12 Optical Link Module

CPU417H Central Processor for S7-400H

CENTRAL PROCESSING UNIT
24 VDC
SIMATIC S7-400H
CPU 417H
1 MPI/DP
1 DP
2 FOR SYNC MODULES
20 MB MEMORY

CP 343-5 Profibus

BDPSboard

BDPS-11C
3AXD50000000051
Braking Chopper System
Input Voltage (DC):1000–1200 V DC link
Max. Braking Power:250–1000 kW
Certifications"CE, UL, and IEC 61800-5-1
Operating Temperature: -15°C to +45°C

IGBT Module

Product:IGBT Silicon Module
Configuration: 6-Pack
Collector- Emitter Voltage VCEO Max:1.7 kV
Continuous Collector Current at 25 C:740 A
Gate-Emitter Leakage Current:400 nA
Pd - Power Dissipation:3 kW
Minimum Operating Temperature:- 40 C
Maximum Operating Temperature:+ 150 C
Packaging:Tray
Product Type:IGBT Modules

PanelView Plus 7 Graphic Terminal

PanelView Plus 7 Performance terminals
Operator Input:Touch
Touch screen: Analog resistive touchscreen
Actuation rating:1 million presses
Operating force:100 grams
Display Type:Color active-matrix TFT
Input Voltage range:18-30 VDC
Power Consumption:50 W max (2.1 A at 24V DC)

Micromaster 440

Mechanical protection card

Accuracy: ≤±1.5%
Linear error: ≤±0.5%
Output allowable load: >100 kΩ voltage output.< 325Ω current output.
Characteristics of relay
Trunk name: RL1 to RL4
Rated voltage: 250 VAC
Rated current: 5 AAC
Maximum breaking capacity (no contact protection) : 1250 VA

Serial Interface Module
