AI 8 CH 4-20mA HART CARDSERIES 2
Local Bus Power:12 VDC at 150 mA
Bussed Field Power:24 VDC at 300 mA
Field Circuit: 24 VDC at 30 mA/Ch.
Ambient Temperature -40 °C to +70 °C
Shock 10 g half-sine wave for 11 ms
Vibration 1 mm peak to peak from 2 to 13.2Hz
0.7 g from 13.2 to 150 Hz
AirborneContaminantsISA-S71.04 –1985
AirborneContaminants Class G3
Relative Humidity:5 to 95% Non-Condensing
Analog Output Module
Output Type:4-20 mA
Output Channels:16
Output Temperature Stability ±0.02% Full Scale/°C
Output Readback Accuracy ±4%
Output Current Linearity ± 0.05% nominal
Resolution ± 0.05%
Maximum Output Compliant Voltage:15 V
Maximum Resistive Load:750 Ω @ 20 mA
CABLE
Series:RX3i PacSystem
Part Number:IC695CBL001
Compatibility:PACSystems RX3i
Cable Type:Energy pack cable
Type of Input/Output:Analog
Termination Resistor:Yes
Power Supply Drives Control Board
CT PP C902 AE101 AMC-33
PP C902 AE101 AMC-33
APPLIC.& MOTOR
150 Mhz
AMC-33 board has limited availability.
Analog Output Module
Analog Output w/o HART
Extensive self-diagnostics
Optional redundancy
Safe-state (FAILOPT)
behaviors configurable ona per channel basis
Analog Output Module
Analog Output (AO) Module
Extensive self diagnostics
Optional redundancy
Series 8 AO module supports
Low Level Analog (Temperature) Input
Low-level AI IOTA
TC and RTD operation
Remote Cold Junction compensation capability
Second PV scanning with OTD protection
Configurable OTD protection (See below)
Temperature points can be added in 16 pointincrements
Centrifugal Cooling Fan Assembly
Humidity class F2-1
Max. permissible ambientmotor temp. + 80 °C
Min. permissible ambientmotor temp.- 40 °C
Mounting position Any
Operation mode S1
Motor bearing Ball bearing
Leakage current < 0.75 mA
Motor protection Thermal overload protector (TOP) brought out
