Bently Nevada

3300 XL NSv Proximitor Sensor

70 7.0 meters (23.0 feet) systemlength
panel mount
05 Multiple approvals
3300 XL NSv Proximitor Sensor

Velomitor Piezo-velocity Sensors

03 1/4 - 28 UNF
00 Not required
Connector 2-pin Mil-C-5015hermetically-sealed
316Lstainless steel shell

3300 XL 8 mm Reverse Mount Probes

Total length option : 10 = 1.0 metre (3.3 feet)
Connector option : 02 = Miniature ClickLocTM coaxial connector
Agency approval option : 00 = Not required
Probe tip material : Polyphenylene sulfide (PPS).
Probe case material : AISI 303 or 304 stainless steel (SST).

3300 XL 11 mm Proximitor Sensor

50 5.0 meter(16.4 feet) systemlength
panel mount
05 Multiple approvals

Proximitor Sensor

71 7.0 meters (23.0 feet) systemlength
DIN mount
05 Multiple approvals
3300 XL NSv Proximitor Sensor

Hydro Monitor

Powerconsumption 7.7 watts, typical
Multimodepositive inputI/O 50 kΩ
Direct filter0.104 Hz to 500 Hz
Rotor speed is 25 to 1,500 cpm.
Gap filter -3 dB at 0.05 Hz
Direct filter -3dB at 1.2 Hz

Velomitor Piezo-velocity Sensor

Sensitivity3.94mV/mm/s (100 mV/in/s)±5%
Velocity Range 1270 mm/s (50 in/s) peak.
TransverseSensitivityLess than 5% of sensitivity
AmplitudeLinearity±2% to 152 mm/s (6 in/s)peak.
Output BiasVoltage-12 ±3.0 VDC
overtemperature referenced toPin A
DynamicOutputImpedanceLess than 2400 Ω
Grounding Case isolated

3300 NSv Proximity Probes

330910 3300 NSv Probe
M10X1 thread, witharmor
Minimum unthreaded length:0 mm
Minimum length: 120 mm
10 1.0 meter (39 in)
02 Miniature coaxial ClickLoc connector
standard cable
00 Not required
