ALL MANUFACTURERS

Electronic Module

SIMATIC DP
distributed I/O
DP/RS 232C LINK Converter from
PROFIBUS DP to
RS 232C interface

Digital input module

SIMATIC S5
Analog input 464
Isolated for
ET 100U 4 inputs
+-50mV with linearization

Digital input module

SIMATIC S5
Digital input 430
Isolated for S5-90U/-95U/-100U
ET 100U,
ET 200U 4 inputs 230V UC

Digital input module

SIMATIC S5
Digital input 431
Isolated Compact
design U 16 inputs
24V/48V/60V DC

DIGITAL OUTPUT MODULE

SIMATIC S5
Digital output 454-4
Isolated Compact
design 16 Outputs
24/60 V DC

FlexLogix Extended-local IO Adapter

Product Type:FlexLogix Extended-local IO Adapter
Input Voltage:24V DC
Input Current:0.39A max. @ 19.2V DC; 0.25A max. @ 24V DC
Input Voltage Range:19.2-31.2V DC
Flexbus Output Current:653mA max. @ 5.1V DC
Isolation Voltage:30V DC
Power Connector Torque:0.6-0.8 Nm
Power Dissipation:7.5W max @ 19.2V; 6.0W max. @ 24V DC
Thermal Dissipation:25.6 BTU/hr. @ 19.2V

Power supply module

SIMATIC S5
power supply 955
for ZGS5-135U/-155U
EG 185U
230/120 V AC
5 V, 40 A

Contactor

220-230V 50Hz / 230-240V 60Hz
Model Number: A30-30-10
Rated Operational Current (Ie): 30 A
Rated Operational Voltage (Ue): Up to 690 V AC
Control Voltage: 24-230 V AC/DC
Poles: 3 (3-phase)
Mechanical Life: Up to 10 million operations
Electrical Life: Up to 1 million operations
Enclosure Rating: IP20

Frequency converter

ACS510-550 Frequency converter
Model Number: 3X4K7 10028493B
Input Voltage: 3-phase, 380-480 V AC
Output Voltage: 0-480 V AC
Frequency Range: 0-400 Hz
Rated Power: 7.5 kW (10 HP)
Current Rating: 16 A
Enclosure Rating: IP20 (suitable for panel mounting)
Cooling Method: Air-cooled

power supply module

POWER SUPPLY MODULE
220 V AC INPUT
50/60 HZ
0.5 AMPS
5 V DC OUTPUT
8 AMPS

Main Circuit Interface Board

Manufacturer: ABB
Model: RINT-6512C
Type: Main Circuit Interface Board
Function: Interfaces between control logic and power circuits in drives/inverters.
Voltage Rating: 24V DC
Temperature Range: -20°C to +70°C.
Humidity: Up to 95% (non-condensing).

Driver board

RINT-6421C
68638721C
Supply Voltage:24 V DC (±10%)
Power Consumption:1.5 W
Isolation:500 V AC

Digital valve amplifier

Operating voltage UB 24 VDC
Upper limit value uB(t)max 30 V
Lower limit value uB(t)min 21 V
Current consumption Imax 1.5 A; standby current 270 mA
Fuse IS 4 A time-lag
Digital inputs Signal log 0 = 0 to 5 Vlog 1 = 16 V to U
Range U ±10 V
Input resistance Re > 100 kΩ, > 10 MΩ for input AI2
Resolution 5 mV for range ±10 V

PCB BOARD

RATED VOLTAGE: 0...793 VAC / 0...650 VDC
SUPPLY VOLTAGE: 88....264 VAC / 77...286 VDC
POWER CONSUMPTION: 14 VA
RELAY CONTACTS: 5 AMP 250 VAC

Processor-based VME (VMEbus) single board computer

Up to 512MB PC133 SDRAM
Built-in SVGA support with 4 Mbytes DRAM display cache
Built-in dual 10/100 Mbit Ethernet
IDE drive support
Floppy drive support
Two RS232 serial ports
Dual USB ports
Real-Time clock/calendar
Front panel reset switch
Miniature speaker
Keyboard/Mouse port

Pcb board

Operating Temperature Range: -40°C to +70°C.
Power Consumption: Maximum of 5W
Data Transfer Rate: Up to 400 Mbps
Digital I/O Channels: Provides 32 digital

Pcb board

Operating Temperature Range: -40°C to +70°C.
Power Consumption: Maximum of 5W
Data Transfer Rate: Up to 400 Mbps
Digital I/O Channels: Provides 32 digital

Pcb board

1 PORT CHANNEL
Operating Temperature Range: -40°C to +70°C.
Power Consumption: Maximum of 5W
Data Transfer Rate: Up to 400 Mbps
Digital I/O Channels: Provides 32 digital

PROFIBUS INTERFACE CARD

PROFIBUS INTERFACE CARD
1 PORT CHANNEL
Operating Temperature Range: -40°C to +70°C.
Power Consumption: Maximum of 5W
Data Transfer Rate: Up to 400 Mbps
Digital I/O Channels: Provides 32 digital

I/O Modnet 1/D

CBK 132.1 029.210
753 Serial
I/O Modnet 1/D

32bit-contr，W，|/O peri

CCU 132.08 590.037498
32bit-contr，W，|/O peri

3300 XL 8 mm Proximity Probes

330101  3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Minimum unthreaded length: 1.3 in
Minimum case length:3.7 in
10 1.0 meter (3.3 feet)
12 Miniature coaxial ClickLocconnector
FluidLoc cable
05 CSA, ATEX, IECEx  Approvals

3300 XL 8 mm Proximity Probes

330101 3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Minimum unthreaded length: 3.2 in
Minimum case length: 7.0 in.
10 1.0 meter (3.3 feet)
12 Miniature coaxial ClickLocconnector
FluidLoc cable
05 CSA, ATEX, IECEx  Approvals

3300 XL 11 mm Probe

330708 3300 XL 11 mm Probe
5/8-18 UNFthread, with armor
Minimum unthreaded length:0.0 in
Minimum case length: 2.0 in
50 5.0 meters (16.4 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

3300 XL 8 mm Proximity Probes

330102  3300 XL 8 mm Probe
3/8-24 UNFthread, with armor
Minimum unthreaded length: 0.0 in
Minimum case length: 2.0 in
50 5.0 meters (16.4 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required
