3300 NSv Extension Cable

065 6.5 meters (21.3 feet)
01 With stainless steel armor
withFEP jacket
3300 NSv Extension Cable

3300 NSv Proximity Probes

330902 3300 NSv Probe
1/4-28 UNF thread,with armor
Minimum unthreaded length: 0.0 in
Minimum case length: 9.5 in
10 1.0 meter (39 in)
02 Miniature coaxial ClickLoc connector
standard cable
00 Not required

3300 NSv Extension Cable

065 6.5 meters (21.3 feet)
01 With stainless steel armor
withFEP jacket
CN Multiple Approvals

Armored cable

84661-75
Armored cable
for 2 -wiretransducer
Machinery Condition Monitoring

3300 XL 8 mm Proximity Probes

330103 3300 XL 8 mm Probe
M10 x 1 thread,without armor
Minimum unthreaded length: 0 mm
Minimum case length: 50 mm
20 2.0 meters (6.6 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

3300 XL 8 mm Proximity Probes

330103 3300 XL 8 mm Probe
M10 x 1 thread,without armor
Minimum unthreaded length: 0 mm
Minimum case length: 100 mm
10 1.0 meter (3.3 feet)
11Miniature coaxial ClickLocconnector
with connectorprotector, FluidLoc cable
05 CSA, ATEX, IECEx  Approvals

3300 NSv Proximity Probe

330903 3300 NSv Probe
M8X1 thread,without armor
Minimum unthreaded length:0 mm
Minimum length: 40 mm
10 1.0 meter (39 in)
02 Miniature coaxial ClickLoc connector
standard cable
05 Multiple Approvals

3300 NSv Proximity Probes

330901 3300 NSv Probe
1/4-28 UNF thread,without armor
Minimum unthreaded length: 0.0 in
Minimum case length: 9.0 in
10 1.0 meter (39 in)
02 Miniature coaxial ClickLoc connector
standard cable
05 Multiple Approvals

3300 XL 8 mm Proximity Probes

330102 3300 XL 8 mm Probe
3/8-24 UNFthread, with armor
Minimum unthreaded length: 0.0 in
Minimum case length: 5.0 in
10 1.0 meter (3.3 feet)
01Miniature coaxial ClickLocconnector
with connectorprotector, standard cable
00 Not required

Thrust Transmitter

25 25-0-25 mils
50 5.0 meters (16.4 feet)
02 Bulkhead screws
05CSA Division 2, ATEX Zone 0
ATEXZone 2 and includes
ABSmaritime approval

3300 XL 11 mm Proximity Probes

330701 3300 XL 11 mm Probe
1/2-20 UNFthread, without armor
Minimum unthreaded length:0.0 in
Minimum case length: 4.0 in
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 Multiple Approvals

Digital Signal Processor Board

CONTROL BOARD
DIGITAL SIGNAL PROCESSOR
60 MHZ
MARK VI
Clock Frequency:Up to 200 MHz
Program Memory:512 KB Flash
Input Voltage:Typically 12 V DC
Power Consumption:Approximately 3–5 W

Current Input Module

Number of input channels
16-channel input, isolated
Input signal 4 to 20 mA
Allowable input current 24 mA
Accuracy ±0.1% of full scale
Data refresh cycle 10 ms
Transmitter power supply 24.0 to 25.5 V
Temperature drift Max. ±0.01%/°C

Current Input Module

Number of I/O channels
8-channel input, isolated channels
I/O signal 4 to 20 mA
Allowable input current 25 mA
Accuracy ±16 µA
Data update period 10 ms
Temperature drift ±16 µA/10 °C
Maximum currentconsumption
360 mA (5 V DC), 450 mA (24 V DC)

ELECTRONIC MODULE

SIMATIC DP
ELECTRONIC MODULE
ET200S: 2AI HIGH SPEED I2WIRE
0 - 20MA, 4 - 20MA, 15BIT
15 MM WIDTH,FOR 2-WIRE
TRANSDUCER,CYCLE TIME OF
THE MOD.: 0.1MS,
WITH LED SF (GROUP FAULT)

Isolation Module 4-Port Benefits

High-Speed 1 MS/s 16-bit Isolation Module
(4 ch) High Noise Immunity
Suitable for testing and long-term monitoring
for power generators and multi-output power supplies.
Provides dynamic analysis of multi-channel
data recording applications.
Applicable to DL350 and DL850 series

Vertical 12 volt 5 amp Battery Charger

FREQUENCY RANGE:45 Hz to 65 Hz
VOLTAGE RANGE:90 V to 305 V (L-N)
DC OUTPUT:5 A DC 12 V DC
RIPPLE AND NOISE:<1%
EFFICIENCY:>80%
LINE:<0.001% Vo
LOAD:1% Vo

Vertical 24 volt 5 amp Battery Charger

FREQUENCY RANGE:45 Hz to 65 Hz
VOLTAGE RANGE:90 V to 305 V (L-N)
DC OUTPUT:5 A DC 24 V DC
RIPPLE AND NOISE:<1%
EFFICIENCY:>80%

24 Volt 5 Amp Compact Battery Charger

VOLTAGE RANGE:90 V to 305 V (L-N)
DC OUTPUT:5 A DC 24 V DC at 13.7 V DC
RIPPLE AND NOISE:<1%
EFFICIENCY:>80%
REGULATION LINE：<0.001% Vo
LOAD：1% Vo

12 volt 5 amp Compact Battery Charger

AC SUPPLY VOLTAGE RANGE
90 V to 250 V (L-N)
DC OUTPUT
5 A DC 12 V DC at 13.7 V DC
RIPPLE AND NOISE:<1%
EFFICIENCY:>80%
REGULATION LINE:<0.001% Vo
LOAD:1% Vo

Auto Transfer Switch & Mains Control Module

CONTINUOUS VOLTAGE RATING
8 V to 35 V continuous
CRANKING DROPOUTS
Able to survive 0 V for 50 mS,
providing supply was at least 10 V
before dropout and supply recovers to 5 V.
This is achieved without the need for internal batteries
MAXIMUM OPERATING CURRENT
460 mA at 12 V, 245 mA at 24 V
MAXIMUM STANDBY CURRENT
375 mA at 12 V, 200 mA at 24 V
CHARGE FAIL/EXCITATION RANGE
0 V to 35 V

Failure Load Share Control Modulee

CONTINUOUS VOLTAGE RATING
5 V to 35 V continuous
CRANKING DROPOUTS
Able to survive 0 V for 100 mS,
providing supply was at least 10 V
before dropout and supply recovers to 5 V.
This is achieved without the need for internal batteries
MAXIMUM OPERATING CURRENT
530 mA at 12 V, 280 mA at 24 V
MAXIMUM STANDBY CURRENT
320 mA at 12 V, 160 mA at 24 V
CHARGE FAIL/EXCITATION RANGE
0 V to 35 V

Synchronising & Load Sharing Auto Start Control Module

CONTINUOUS VOLTAGE RATING
8 V to 35 V continuous
CRANKING DROPOUTS
Able to survive 0 V for 50 mS,
providing supply was at least 10 V
before dropout and supply recovers to 5 V.
This is achieved without the need for internal batteries
MAXIMUM OPERATING CURRENT
460 mA at 12 V, 245 mA at 24 V
MAXIMUM STANDBY CURRENT
375 mA at 12 V, 200 mA at 24 V
CHARGE FAIL/EXCITATION RANGE
0 V to 35 V

Auto Mains (Utility) Failure Control Module

CONTINUOUS VOLTAGE RATING
8 V to 35 V Continuous
Able to survive 0 V for 50 mS
providing supply was at least 10 V
before dropout and supply recovers to 5 V
This is achieved without the need for internal batteries
LEDs and backlight will not be maintained during cranking
MAXIMUM OPERATING CURRENT
85 mA at 12 V, 96 mA at 24 V
MAXIMUM STANDBY CURRENT
51 mA at 12 V, 47 mA at 24 V

Auto Mains (Utility) Failure Control Module

Able to survive 0 V for 50 mS
providing supply was at least 10 V
efore dropout and supply recovers to 5 V
This is achieved without the need for internal batteries.
LEDs and backlight will not be maintained during cranking
CONTINUOUS VOLTAGE RATING
8 V to 35 V Continuous
MAXIMUM OPERATING CURRENT
85 mA at 12 V, 96 mA at 24 V
MAXIMUM STANDBY CURRENT
51 mA at 12 V, 47 mA at 24 V
MAXIMUM SLEEP CURRENT
35 mA at 12 V, 32 mA at 24 V
MAXIMUM DEEP SLEEP CURRENT
<10 uA at 12 V, <10 uA at 24 V
