ALL MANUFACTURERS

EXTENSION I/O BOARD

contains more channels
16 binary inputs
8 binary outputs
8 analog inputs
4 analog outputs
Time out setting by software
Watchdog function

ArmorBlock Guard I/O Input/Output Module

3300 XL Standard Extension Cable

080 8.0 meters (26.2 feet)
10 FluidLoc cable
05 CSA, ATEX, IECEx  Approvals
MaximumConnectorTorque0.565 N•m (5 in•lbf)
Two 3300 XLgold "click"typeconnectorsFinger tight

Network Communication Module

Input Voltage: 24 VDC
ower Consumption: 5 W
Modbus TCP/IP
Ethernet/IP
OPC (as applicable)

I/O CARD

I/O CARD
PADDLE BOARD
CLCN-A
paddle board in a dual-node chassis
to connect the LCN interface with the LCN 'A' cable
The 'B' cable is attached to
the CLCN-B paddle board
in the same chassis

I/O CARD

paddle board
in a dual-node chassis
connect the LCN interface
with the LCN 'B' cable.
The 'A' cable is attached
to the CLCN-A paddle board
in the same chassis.
CE-compliant version of the paddle board

15 INCH QP+ GE BEZEL

Discrete input module

Series:PACSystem RX3i
Manufacturer:GE Fanuc
Part Number:IC694MDL240
Description:Input module
No of Channels:Sixteen (16)
Points:16
Input signal range:0-132 VAC
Voltage:120 Volts AC
Nominal Input voltage:0-120 VAC
Current:7 milliamps
Input Frequency:47-63 Hz
Power consumption:90 milliamps
Input current:12mA per channel
Input current:12 mA
Bus voltage:5 Volts
Current draw:90 mA (all inputs active)
Off response time, maximum:45 ms
On state current:6 mA
On response time, maximum:30 ms
Product Lifecycle Status:Active
Off state current:2.2 mA
On–state Current:6mA minimum
On response time, typical:30 ms

Rectifier interfaces Module

Rectifier interfaces Module
PER3 for infeed
regenerative feedback Supply units
with Designs H and K 380-480 V 3 AC
50/60 Hz
