3300 XL Standard Extension Cable

3300 XL Standard Extension Cable
075 7.5 meters (24.6 feet)
00 Standard cable
05 CSA, ATEX, IECEx  Approvals

SIMATIC HMI TP1900 COMFORT

S7-HMI MMC 128MB

Level Control Transmitter

ELECTRONICS MODULE
FOR AT100 / AT200 LEVEL TRANSMITTER
HART
ABB
(REPLACED BY M4A-AT-2017)

Asymmetric Thyristor IGCT

Asymmetric Integrated GateCommutated Thyristor
VDRM = 4500 V , ITGQM = 4000 A
Mounting force 40kN
High snubberless turn-off rating
Optimized for medium frequency
High electromagnetic immunity
Simple control interface with status feedback
AC or DC supply voltage
Option for series connection

Reverse Conducting Thyristor IGCT

Reverse Conducting Integrated Gate-Commutated Thyristor
VDRM = 4500 V ,ITGQM = 3600 A ,ITSM = 20·10³ A
VT0 = 1.24 V , rT = 0.51 mΩ ,VDC = 2800 V
Mounting force 41kN
High snubberless turn-off rating
Optimized for medium frequency
High electromagnetic immunity
Simple control interface with status feedback
AC or DC supply voltage
Option for series connection

Analog Output Module

Printed Circuit Board

Layer Count:4-layer PCB
Material:FR-4 (Flame Retardant)
Copper Weight:1 oz/ft² (35μm)
Operating Voltage:24V DC (±10%)
Power Consumption:15W (max)
Input Channels:8 analog (16-bit resolution)
Output Channels:6 digital (2A max)
Isolation Voltage:2500V AC

CHOPPER CONTROL BOARD

Model Number:NBRC-61C (61357246F)
Type:Chopper Control Board
Operating Voltage:24V DC (±10%)
Power Consumption:8W (typical)
Signal Levels:0-10V analog, 24V digital
Isolation Voltage:1500V AC (input-to-output)
PWM Frequency:2kHz (adjustable)
Current Regulation:±1% of setpoint
Response Time:<5ms (90% step change)
Resolution:12-bit (analog signals)

Analog Control Module

Operating Voltage:24V DC (±10%)
Power Consumption:6W (typical)
Input Channels:16 digital (24V)
Output Channels:8 relay (5A @ 230V AC)
Isolation Voltage:1500V AC (field to logic)
Processor:32-bit RISC
Clock Speed:100MHz
Memory:2MB Flash, 512KB RAM
Scan Time:1ms (typical)
