SIMATIC DP
INTERFACE MODULE IM151-1STANDARD
FOR ET200S; TRANSMISS
RATE UP TO 12MBIT/S
DATA VOLUME 128BYTE FOR
EACH INPUT AND OUTPUT
MAX.OF 63 POWER, ELECTR
OR MOTOR STARTER MODULES
UPTO 2M WIDTH CONNECTABLE
BUS INTERFACING VIA 9-WAYSUB-D
INCL. TERMINATING MODULE
Number of outputs 16-channel, module isolation
Output voltage 24 V DC
Output voltage drop 1 V maximum
External power supply rating 24 V DC, 3.4 A minimum
Maximum leak current at output off status 1.6 mA
Output format Current source
Maximum load current 0.2 A/output line
Minimum load current 35 mA
Load resistance range 120 to 685 Ω
Output response time 30 ms maximum
Number of input channels:16, isolated
Input signal:4 to 20 mA
Allowable input current:24 mA
Accuracy:±16 µA
Data update period:10 ms
Drift due to ambient temperature change:±16 µA/10 ˚C
Maximum current consumption:230 mA (5 V DC), 540 mA (24 V DC)
Function: ESB bus master interface function
Number of connectable units: 9 units maximum
Transmission speed: 128 Mbps
(I/O module data transmission)
Transmission distance: 10 m maximum
Current consumption: 0.5 A
