ALL MANUFACTURERS

FAN

Voltage: 230V AC
Frequency: 50/60 Hz
Current Consumption: Approximately 0.3A
Power Consumption: Around 65W
Airflow: Approx. 280 m³/h (165 CFM)
Speed: 2650 RPM
Noise Level: Approx. 55 dB(A)

POWER MODULE

SIMODRIVE 611
POWER MODULE
2 AXES, 50A
INTERNAL HEAT DISSIPATION
RATED MOTOR CURRENTS:
FEED = 18 A MAIN
SPINDEL = 24 A

Swappable lens with C-mount connection

suitability for use Swappable lens with C-mount connection
suitability for operation lens for MV440
mechanical datacolor black
design, dimensions and weight
sheight 37.2 mm
diameter 29.5 mm

Kinetix 300 Servo Drive

120 Volts Doubler Mode:Yes
Continuous Output Current (0-peak):5.7 Amperes
Integrated AC (EMC) Line Filter:No
Input Voltage:120/240 Volts (AC), 1 Phase
Power Rating:800 W
Part Number/Catalog No.:2097-V31PR2-LM
Safe Torque-Off:Yes

ARMOR WELDBLOCK

ARMOR WELDBLOCK
16 POINT CONFIGURABLE
QUICKCONNECT
5-PIN AUXILIARY POWER CONNECTOR
SCREW MOUNTED

DeviceNet Scanner Module

Module Width:Single Slot
Compatible controllers:SLC 5/02 or later
Pass through:Supported
Communication Port:One (1) DeviceNet
Data Transfer speed:125Kbps
Storage Temperature:-40 to 85 C (-40 to 185 F)
Vibration:Tested 5 g @ 10-500Hz per IEC 68-2-6
Operating Shock:30 g peak acceleration, 11(+1)ms pulse width
Series:SLC 500
Module Type:DeviceNet Scanner Module
Scan I/O:Yes
Backplane Current (5 Volts):500 milliamps

Process Module

PROCESS MODULE
XM-360
6-CHANNEL INPUT
0-10 VDC/0-20 MA INPUT RANGE
4-20 MA OUTPUT
600 OHM MAX LOAD
STATUS INDICATORS
RS-02232 VIA MINI-CONNECTOR
COMM RATE FIXED @ 19.2 KBPS
STANDARD DEVICENET NETWORK

POINT I/O Analog Input Module

Series:POINT I/O
Module Type:Analog Input Module
Inputs:2 single-ended, non-isolated, voltage
Signal Type:Voltage
Conversion Type:Delta Sigma
Absolute Accuracy:0.1% Full Scale @ 25 °C (77 °F)
Data format:Signed Integer
Key Switch Position:3
Enclosure Type Rating:Open

Processor board

AC 800M series systems
Voltage Supply: Typically 24 VDC
Operating Temperature Range: -20°C to +60°C
Storage Temperature Range: -40°C to +85°C.
Humidity: 5% to 95%

DC-powered sink output module

Module Type:Digital DC Output Module
Number of Outputs:32 (4 sets of 8) Outputs
Voltage Category:10-32 Volts DC, Sink
DC Operating Voltage:10-30 Volts
Backplane Current:330 Miliamperes
Max Continuous Current Per Output:0.5 Amperes
Max Continuous Current Per Module:8 Amperes
Wiring Arm:1771-WH
Coating:Conformal Coat
Typical AC Signal Delay (Off):45 (+/- 15) ms

Stratix 5700 managed Ethernet switch

Part Number:1783-BMS06SL
Product type:Managed Ethernet switch
Ports:6
Copper ports:4
Fiber ports:2
Input voltage:12 to 48 Volts DC
Operating temperature:-40 to 60 degrees Celsius

DeviceNet Master Module

Series:PACSystem RX3i
Product Description:DeviceNet Master Module
Part Number:IC694DNM200
Communication protocol:DeviceNet
Maximum Number of Slave Devices Supported:63
No. of supported DeviceNet slave:63
Slave Operation:Supported
Input data:255 Bytes
Communication Rates:125k, 250k, or 500k bauds
Output data:255 Bytes

ArmorBlock MaXum I/O Cable

ArmorBlock
MaXum I/O Cable
Base with 18 mm
round media connectors
and jumpered DeviceNet power

4-Ch Universal Analog Inputs

Input Types:4 V, C, or 3 TC, or 2 RTD, Resistance
Resolution:18 bits
Input Overvoltage Protection:+24 VDC continuous
Input Overcurrent Protection:32 mA continuous
Backplane Current Required:15 mA at 5 V maximum  20 mA at 24 V maximum
Common Mode Rejection:<96 dB at 50/60 Hz
Normal Mode Rejection:65 dB to 74 dB at 50/60 Hz
Thermal Dissipation:1.00 Watt, maximum

4-Ch Universal Analog Inputs

Input Types:4 V, C, or 3 TC, or 2 RTD, Resistance
Resolution:18 bits
Input Overvoltage Protection:+24 VDC continuous
Input Overcurrent Protection:32 mA continuous
Backplane Current Required:15 mA at 5 V maximum  20 mA at 24 V maximum
Common Mode Rejection:<96 dB at 50/60 Hz
Normal Mode Rejection:65 dB to 74 dB at 50/60 Hz
Thermal Dissipation:1.00 Watt, maximum

ControlNet Ex communication adapter

I/O Capacity:8
Communication Rate:5 Mbps
Output Power:5.4 Volts DC
Power Supply:9.5 Volts DC
Power Consumption:8.5 W
Power Dissipation:8.5 W
Thermal Dissipation:29 BTU/hour

Variable speed drive

Supply voltage:3 × 380 VAC -10 %...3 × 500 VAC +10 %
Supply frequency:.50 Hz...60 Hz ±5 %
Rated system current: 5.0 AAC  6.2 AAC
Rated output power: 3.8 kVA
Rated output current:5.5 AAC
Minimum permitted brake:68 Ω
PWM frequency:Adjustable: 4/8/16 kHz
Speed range / resolution:-5000...0...+5000 rpm
0.2 rpm across the entire range
Power loss at PNPVmax: 105 W

managed layer 2 IE switch

SCALANCE XB205-3LD
managed layer 2 IE switch
5x 10/100 Mbit/s RJ45 ports
3x SM FO SC-port 1x console port,
diagnostics LED redundant power supply
IEC62443-4-2 certified
temperature range 0 °C to +60 °C
DIN-rail mounting; defaultPROFINET

AMP MODULE

Configurable high-pass and low-pass filters
Frequency range: 0.5 Hz to 20 kHz
Optional integrator to produce a velocity output
Optional 2-wire current or 3-wire voltagetransmission
Certified for use in potentially explosiveatmospheres
A range of installation options are available

AMP MODULE

Configurable high-pass and low-pass filters
Frequency range: 0.5 Hz to 20 kHz
Optional integrator to produce a velocity output
Optional 2-wire current or 3-wire voltagetransmission
Certified for use in potentially explosiveatmospheres
A range of installation options are available

IGBT Module

Voltage Rating: 1200 V
Current Rating: 450 A
Configuration: Sixpack
Technology: IGBT3 – E3
Package Type: EconoPACK™ + B

IKB Keyboard

Model Number: 51196694-350/U1
AID-3 9395-00379-034/B
Key Layout: 101 keys, including a numeric keypad.
Cable Length: 3 meters.
Compatibility: Designed for use with
Honeywell industrial control systems

VSC power board

1VCR017053G0006
V-Contact VSC contactors
VSC power board

Gas Detection Monitor

Power Consumption: 7.0 Watts, typical
External transducerPower+24 Vdc +4
-2 Vdc @ 1.8 AMinimum
Voltage +5 Vdc typica
Current 0.4 mA typical, 4 mA peak
OperatingTemperature:-30°C to +65°C

Thermocouple I/O Module

Product Type:FLEX Ex RTD Thermocouple I/O Module
Inputs:8
Input Type:Internal Bus Configurable
Signal Input Range:40 to 100 millivolts
Lead Resistance Compensation:15 Watts maximum
Settling Time:8 milliseconds
Module Field-side Power Consumption:1.6 Watts
Power Dissipation:1.6 Watts
Thermal Dissipation:5.46 BTU/hour maximum
Power Supply:9.5 Volts DC
