Interface Main Circuit Board

ACS600 Fiber-optic communication board
MAIN CIRCUIT INTERFACE BOARD
GIVES CONTROL COMMANDS
SENDS MEASUREMENT SIGNALS
Number: Up to 16 channels
Connectors: ST/SC-type
Isolation Voltage: 2500 V

Matching Board

PCB MATCHING BOARD
CIRCUIT BOARD MODULE
58908096
Operating Voltage: 24 V DC (±10%)
Power Consumption: <5 W
Analog: +/-10 V DC or 4–20 mA
Digital: 24 V DI/DO

INTERFACE BOARD

ACS880-XINT INTERFACE BOARD
KIT A-4-8-290
R8i DC BUSB
W400

IGBT MODULE KIT SP

IGBT MODULE KIT SP
IGBT MODULE ED3 225A/1700V SP
Semiconductor spare part kit
to be used with ACS880-104 modules

Communication Board Kit

Remote Monitoring
Communication Board Kit
Input Voltage: 24 V DC (±20%)
Power Consumption: < 5 W
Ethernet Port:10/100 Mbps RJ45
Serial Port(s):RS-485 / RS-232

LINE REACTOR

SINAMICS LINE REACTOR
FOR 10 KW SMART LINE MODULE
INPUT: 3-PH 380-480 V
50/60 HZ

Power Block Drive Board

Power Block Drive Board
DC Link Voltage: 510–720 V DC
AC Output Voltage:400 V AC
Continuous Output: Up to 100–280 A (rms)
Cooling Method: Liquid or forced-air cooling
Thermal Resistance: < 0.05 K/W

TM120 TERMINAL MODULE

SINAMICS TERMINAL MODULE
CABINET TM120
WITHOUT DRIVE-CLIQ CABLE ADD ON BOARD
FOR SINAMICS CONVERTERS
PTC and KTY analog inputs
with safe electrical isolation

OUTPUT POWER UNIT

OUTPUT POWER UNIT
PEU ASSEMBLY
17.5 A
380-460 V AC
50/60 HZ

Inverter Power Drive Module

Micromaster 440
18.5/22/37KW
Voltage: 3 AC 380–480 V ±10% (50/60 Hz)
Frequency Range: 0–650 Hz
Switching Frequency: 4 kHz
Ambient Temperature: -10°C to +50°C
Humidity: Up to 95% (non-condensing)

Single Motor Module

SINAMICS S120
Single Motor Module
input: 600 V DC
output: 400 V 3 AC,
9 A type of construction: booksize
internal air cooling optimized pulse patterns
and support of the extended Safety
Integrated functions incl. DRIVE-CLiQ cable

MASTERDRIVES ACCESSORY PACK

MASTERDRIVES ACCESSORY PACK
SIMOVERT
FOR COMMUNICATION MODULE SIMOLINK SLB
5 M PLASTIC FIBER-OPTIC CABLE
2 FOC CONNECTOR
SAND PAPER FOR WORKING INTERFACE

BRAKING MODULE

SINAMICS BRAKING MODULE
INPUT: 1035 V DC
OUTPUT: 250 KW/15 S
FOR CHASSIS UNITS
HX AND JX

INTERFACE SUB MODULE

SIMADYN D
INTERFACE SUB MODULE
SS1 20MA (TTY)

3300 NSv Proximity Probes

330908 3300 NSv Probe
3/8-24 UNF thread,without armor
10 1.0 meter (39 in)
02 Miniature coaxial ClickLoc connector
standard cable
05 Multiple Approvals

3300 XL 8 mm Proximity Probes

330910 3300 NSv Probe
M10X1 thread, witharmor
10 1.0 meter (39 in)
02 Miniature coaxial ClickLoc connector
standard cable
00 Not required

3300 XL 8 mm Proximity Probes

330103 3300 XL 8 mm Probe
M10 x 1 thread,without armor
05 0.5 meter (1.6 feet)
01Miniature coaxial ClickLocconnector
with connectorprotector, standard cable
05 CSA, ATEX, IECEx  Approvals

3300 NSv Proximity Probes

330904 3300 NSv Probe
M8X1 thread, witharmor
05 0.5 meter (20 in)
01Miniature coaxial ClickLoc connector
with connector protector, standardcable
05 Multiple Approvals

3300 NSv Proximity Probes

330901 3300 NSv Probe
1/4-28 UNF thread,without armor
05 0.5 meter (20 in)
02 Miniature coaxial ClickLoc connector
standard cable
05 Multiple Approvals

3300 NSv Proximity Probes

330901 3300 NSv Probe
1/4-28 UNF thread,without armor
05 0.5 meter (20 in)
02 Miniature coaxial ClickLoc connector
standard cable
05 Multiple Approvals

3300 NSv Proximity Probes

330903 3300 NSv Probe
M8X1 thread,without armor
10 1.0 meter (39 in)
01Miniature coaxial ClickLoc connector
with connector protector, standardcable
00 Not required

3300 XL 25 mm Proximity Probe

02 M30x2 Thread
066 = 66 mm
10 1.0 metre (3.3 feet)
00 No Armor
00 No Approvals

3300 NSv Proximity Probes

330901 3300 NSv Probe
1/4-28 UNF thread,without armor
05 0.5 meter (20 in)
02 Miniature coaxial ClickLoc connector
standard cable
00 Not required

3300 XL NSv Proximity

330903 3300 NSv Probe
M8X1 thread,without armor
05 0.5 meter (20 in)
02 Miniature coaxial ClickLoc connector
standard cable
05 Multiple Approvals

Velomitor Piezo-velocity Sensors

03 1/4 - 28 UNF
01 CSA/US/C
PIEZO VELOCITY SENSOR
100MV/IPS 4MV/MM/S
