ALL MANUFACTURERS

Inverter drive transformer

5046X005
TRANSFORMER
FOR INVERTED DRIVE
24 VOLT
10 PIN

VLT Decentral Drive

FCD322-P-T4-P66-STR1-DC-F00-T52-C0
DRIVE
FCD322
DECENTRAL DRIVE
3 HP
STANDARD
3 X 380-480V 50-60HZ4-7AMP
3 X 0-UIN 0-1000HZ 3.6KVA
RS485

PACSystems RX3i Universal Backplane

PACSystems RX3i Universal Backplane
(IC695 Series), occupies 1 slot
24 Vdc Nominal Operates 18Vdc to 30 Vdc
40 W Total, All Loads
14 AWG to 22 AWG, 1 wire per terminal
Power, P/S Fault, Overload, Overtemperature

PC CIRCUIT BOARD

C98043A7002L1
PC CIRCUIT BOARD
POWER BOARD
1Q INTERFACE
power interface C98043-A7002-L1 incl

DC REGULATING BOARD

SINAMICS DCM
DC speed regulation excitation board
Output Voltage Range: 0–250 V DC
Field Current Rating: Typically ≤20 A
Enable/Disable Signals: 24 V DC
Temperature Range: 0°C to +55°C (60°C with derating)
Humidity: 5–95% non-condensing

Emergency Turbine Protection Module

Frame Rate Up to 100 Hz
MPU Pulse Rate Range 2 Hz to 20 kHz
Input supply: 125 V dc (70-145 V dc)
Output: 5 V dc and 28 V dc
Input Channels:4–20 mA

HMI

Family:HMI
Series:GP4000 Series
Display type:TFT Color LCD
Display size:7.5"
Resolution:640 x 480 pixels (VGA)
Backlight service life:50,000 hrs. or more

3300 NSv Proximity Probes

3300 NSv Probe
M10 x 1 thread, withoutarmor
0 5 0.5 metre (20 in)
0 2 Miniature coaxial ClickLocconnector
standard cable
0 0 Not required

3300 XL NSv Extension Cable

0 6 5 6.5 metres (21.3 feet)
0 5 With stainless steel armor
without FEP jacket, withconnector protectors
0 0 Not required

3300 NSv Proximity Probes

3300 NSv Probe
M8X1 thread, witharmor
05 0.5 meter (20 in)
02 Miniature coaxial ClickLoc connector
standard cable
00 Not required

3300 NSv Extension Cable

065 6.5 meters (21.3 feet)
04With stainless steel armor
withFEP jacket, with connectorprotector
00 Not Required

3300 NSv Proximity Probes

3300 NSv Probe
M8X1 thread,without armor
05 0.5 meter (20 in)
02 Miniature coaxial ClickLoc connector
standard cable
00 Not required

3300 XL 25 mm Proximitor Sensor

9 19.0 metres (29.5 feet)
systemlength, DIN mount
0 5 Multiple Approvals

3300 NSv Proximity Probes

3300 NSv Probe, M8X1 thread, witharmor
0 1.0 meter (39 in)
02 Miniature coaxial ClickLoc connector
standard cable
05 Multiple Approvals

3300 XL 8 mm Probe

3300 XL 8 mm Probe
M10 x 1 thread,with armor
Minimum unthreaded length: 0 mm
Minimum case length: 110 mm
10 1.0 meter (3.3 feet)
01Miniature coaxial ClickLocconnector with
connectorprotector standard cable
00 Not required

interconnect cable

16710-07
82-inch (2.08 m)
Interconnect Cable
Delivers –24 V DC supply

3300 XL Standard Extension Cable

030 3.0 meters (9.8 feet)
02 Standard cable with connectorprotector
05 CSA, ATEX, IECEx  Approvals
3300 XL Standard Extension Cable

3300 XL 8 mm Probe

3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
20 2.0 meters (6.6 feet)
12 Miniature coaxial ClickLocconnector
FluidLoc cable
00 Not required

Softstarter

Product No. : PSTX300-600-70
Product Type : Softstarter
Current Rating : 300 - 300A
Main Voltage : 600 - 208 - 600V 50/60 Hz
Supply Voltage : 70 - 100 - 250V 50/60 Hz

Control Board

Voltage Inputs:24 V DC
Power Consumption:5 W
Relay Outputs:8 A up to 250 V AC
Digital Inputs:24 V DC inputs
Operating Temp:-25°C to +70°C

Interfaces Module

Power Supply:24 V DC
Ethernet Port (TCP):- 10/100 Mbps RJ45
Modbus RTU (RS485)
Modbus TCP (TCP/IP) compliance
Isolation:1500 V AC
Operating Temp: -25°C to +70°C

C98043A1600L117
CONTROL BOARD
INVERTER POWER BOARD
SIMOREG K

THICK-FILM HYBRID

High Voltage Isolation: Up to 2–4 kV
Resistance Range: 10 Ω–1 MΩ
Power Rating: 0.25–2 W
Voltage Rating: 50–500 V DC/AC
Temperature Range: -55°C to +150°C
RoHS: Lead-free manufacturing.
UL 94V-0: Flame-retardant encapsulation

MicroLogix SSI Interface Module

Two-channel SSI interface
Direct interface to most sensors that output SSI
Onboard diagnostics monitor and report errors
Compatible with leading SSI sensors
Onboard fault diagnostics that
constantly monitor system integrity and report errors

PCB CIRCUIT BOARD

Analog Outputs: 4–20 mA
Voltage: 12–24 V DC
Consumption: ≤5 W
Drive Coil Excitation: 10–50 V AC
Standard: -40°C to +70°C (-40°F to +158°F)
Humidity: 0–95% RH (non-condensing)
