Inverter snubber Module

AC/DC DRIVE
SIMOVERT MASTERDRIVES
675-810 V DC INPUT
500-600 V AC OUTPUT
3 PH
31.7 KW
1200 AMP
IP00
RATING - 1700 KW

TDB MODULE PC BOARD

A5E02822121
TDB MODULE PC BOARD
690VAC
FOR CONVERTER MODULE

Self-Checking Flame Scanner

Self-Checking Flame Scanner
INFRARED SELF-CHECKING
BGC
1 INCH NPT MOUNT
24 VDC
ADJUSTABLE FREQUENCY

AC/DC DIN Rail 48V 10A Power Supply

AC-DC Single output
Industrial DIN rail power supply
Output 48Vdc at 10A
metal case

Digital Tacho interface board

SIMOVERT MASTERDRIVES
INTERFACE MODULE DIGITAL
TACHOM. DTI

SC646-2C Industrial Security Appliance

SCALANCE SC646-2C
Industrial Security Appliance
For protection of devices and networks
manufacturing and the process industry
for protection of the industrial communication with
firewall and VPN
address conversion (NAT/NAPT)
Connection to SINEMA RC
4x ports electrical 10/100/1000 Mbit/s RJ45 and
2x combo port electrical or optical
10/100/1000 Mbit/s RJ45
100 Mbit/s SFP or 1000 Mbit/s SFP

Inverter snubber Module

SIMOVERT MASTERDRIVES 6SE70 AC Drives
DC-Link Voltage Compatible:510–930 V DC
Resistance Rating: 50 Ω @ 500 W
Operating Temperature: -10°C to +50°C

Inverter Snubber Module

Inverter snubber Module SML4
Rated Voltage: 510 V to 930 V
Peak Current Handling: 10–20 A
Operating Temperature: -10°C to +50°C
Storage Temperature: -40°C to +85°C
Humidity: Up to 95% non-condensing

Interface Board

MICROMASTER 430
PX replacement Control
Interface Board
for 380-480 V 3AC
50/60 Hz, 490 A AC Drive

Control Interface Board

MICROMASTER 440PX
Control Interface Board
for 380-480 V 3AC
50/60 Hz, 260 A AC Drive

Control Interface Board

Smart Line Module :6TG38-8AA0
Rated power of the SmartLine Module:710
Power loss 50/60 Hz
Rated voltage:
3-ph. 500 V AC -10 % (-15 % < 1 min)
3-ph. 690 V AC +10 %

Precharging module

6SE7031-7HF84-1HH1
SIMOVERT MASTERDRIVE
PRE-CHARGE MOD
E&F
380-575V
50/60 HZ
460V

POWER SUPPLY BOARD

SINAMICS MICROMASTER PX
POWER SUPPLY BOARD
spare power supply
380-480 V 3AC
50/60 Hz AC Drive Power

CIRCUIT BOARD

6SE7036-1EE85-1HA0
SIMODRIVE DC CONVERTER CONTROL
CIRCUIT BOARD

Pulse Encoder Feedback Optional Board

SIMOVERT SBP Pulse
Encoder Feedback Optional Board
Signal Resolution Support:1024–5000 pulses per revolution
Maximum Input Frequency:≤ 300 kHz
Encoder Supply Voltage:5 V DC or 15–30 V DC

RECTIFIER TRIGGER BOARD

RECTIFIER TRIGGER BOARD
TDB
480 VAC/DC
FOR CONVERTER MODULE

SCANNER MODULE

IC695PNS001
RX3I PROFINET SCANNER MODULE
10/100/1000 WITH FOUR PORTS
1.2AMP @ 3.3VDC
1.1AMP @ 5 VDC
SINGLE SLOT

Frequency Converter Communication Board

Input Voltage: 24 V DC
PROFIBUS DP: Up to 12 Mbps
Modbus RTU: Typically 9600 bps – 115.2 kbps
Operating Temperature:-25°C to +70°C (-13°F to +158°F)
Storage Temperature:-40°C to +85°C (-40°F to +185°F)
Humidity:5% – 95% (non-condensing)
Typical current consumption: < 200 mA

HMI KTP600 Basic Panel

SIMATIC HMI KTP600 Basic Color DP
Basic Panel, key/touch operation
6" TFT display, 256 colors
MPI/PROFIBUS DP interface
configurable as of WinCC flexible 2008 SP2 Compact
WinCC Basic V11/ STEP 7 Basic V11

LOCAL BUS ADAPTER

6SE70900XX844HA0
LOCAL BUS ADAPTER
FOR ELECTRONIC BOX
SIMOVERT MASTERDRIVES

3300 XL Proximitor Sensor

11:1.0 meter (3.3 feet) system length, DINmount
51:5.0 meters (16.4 feet) system length,DIN mount
91:9.0 meters (29.5 feet) system length,DIN mount
00 Not required
Gap Voltage: Standard range -2 V DC to -18 V DC

ADAPTER MODULE

ADAPTER MODULE
SIMOVERT MASTER DRIVES
MOTION CONTROL
FOR COMPACT AND INSTALLATION DEVICES ADB
Voltage Supply: +24 V DC
Operating temperature: 0°C to +55°C

COMMUNICATION MODULE

COMMUNICATION MODULE
SIMOVERT MASTER DRIVES
MOTION CONTROL
CBP2 PROFIBUS
without Connectors

DC FIELD SUPPLY BOARD

FIELD SUPPLY BOARD
DC
SPEED EXCITATION

INVERTER CONTROL MODULE

INVERTER CONTROL MODULE IGD1
SIMOVERT MASTER DRIVES
FOR DEVICES 380-460 V AC
50/60 HZ
510-620 V DC
92A AND 146A
