Bently Nevada

Dual Differential Expansion Monitor

Sensor Input:-24V DC @ 4mA
Analog Output:4-20mA
Relay Outputs:3 per channel
Communication:RS-485 Modbus RTU (optional)
Measurement Range:±4mm (±0.16 in) standard
Resolution:0.1% of full scale
Frequency Response:DC to 10Hz (-3dB)
Channels:2 fully independent monitoring channels

Dual Accelerometer Monitor

1 5 0-25 mm/s pk
1 5 0-25 mm/s pk
val Option0 0 Not required
0 0 None
Measures Absolute Machine Housing
Provides Two Independent Channels
Provides Over 10,000 High-Pass and Low-Pass Filter Combinations

Dual Vibration XY/GAP Monitor

1 5 0-500 µm pp
0 1 3300 8 mm, 3300 XL 8mm
or7200 5 mm and 8 mm
0 3 7200 11 mm Proximitor®Sensor(not XL), 100 mV/mil
0 0 No Relays
0 0 Not required
0 2 Internal

Proximitor Seismic Monitor

Signal Accepts from:1 to 4 proximity
velocity or accelerationtransducer signals
Power consumption:7.7 watts, typical
Standard:I/O 10 kΩ
Output Impedance:550 Ω
Transducer Power Supply:-24 Vdc
Voltage Compliance:0 to +12 Vdc range acrossload

3300 XL 11 mm Probe

330707 3300 XL 11 mm Probe
5/8-18 UNFthread, without armor
Example: 2 40 = 2.0 in
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

3300 XL Proximitor Sensor

3300 XL Proximitor Sensor
11 1.0 meter (3.3 feet) system length
51 5.0 meters (16.4 feet) system length
91 9.0 meters (29.5 feet) system length
05 CSA, ATEX, IECEx  Approvals

Velomitor XA Piezo-Velocity Sensor

Product Type: Piezo-Velocity Sensor
Weight: 156 g (5.5 oz), typical
Diameter: 28 mm (1.1 in)
Height: 73.1 mm (2.88 in)
Case Material: 316L stainless steel
Operating Temperature: -55 °C to +121 °C
Shock Survivability: 5000 g peak, maximum
Relative Humidity: To 100% non-submerged
Magnetic Field: Susceptibility <51 min/s/gauss
Shock Survivability: 5000 g peak, maximum

Internal Barriers Earthing Module

Voltage Rating:250V AC/DC maximum
Current Rating:5A continuous
Isolation Voltage:1500V AC (channel-to-channel)
Resistance:<0.1Ω
Bandwidth:30 kHz
Amplitude Accuracy:3% @ 10 kHz,-15/+10% @ 30 kHz
Phase Accuracy: -11° @ 10 kHz
Amplitude Accuracy:±1%

Interconnect Cable

Product Type : Interconnect Cable
Model : 16710 - TEIP11-PS I/P Converter,
signal converter for standard signals,
with power stage
Cable Length Option : 20 - 20 ft

Interconnect Cable

Length:9 feet (2.74 meters)
Conductors:4 conductors (2 twisted pairs)
Wire Gauge:22 AWG stranded copper
Insulation:Fluorinated Ethylene Propylene (FEP)
Voltage Rating:300V AC/DC

Dual-Channel Proccess Variable Monitor

Supply Voltage:90-264VAC, 47-63Hz or 18-36VDC
Power Consumption:15W typical
Isolation:1500VAC input-to-output
Input Types:4-20mA
Accuracy:±0.1% of full scale
Resolution:16-bit (0.0015% of span)
Sampling Rate:10 samples/second per channel
Analog Inputs:2 isolated channels, 24-bit ADC

3300 XL 8 mm Proximity Transducer

330102-00-50-10-01-05
DISCONTINUED BY MANUFACTURER
PROXIMITY PROBE
3300 XL 8 MM
5.0 INCH OVERALL CASE LENGTH
1.0 M (3.3 FT) TOTAL LENGTH
3/8-24 UNF THREAD
WITH ARMOR

3300 XL 8 mm Probe

3300 XL 8 mm Probe
3/8-24 UNFthread
with armor
Order in increments of 0.1 in.
Standard thread configurations:
Maximum case length: 9.6 in.
Minimum case length: 0.8 in.
Example: 2 4 = 2.4 in.
20 2.0 meters (6.6 feet)
01Miniature coaxial ClickLocconnector
with connectorprotector, standard cable
05 CSA, ATEX, IECEx  Approvals

Interconnect Cable

Voltage Rating: ≤300 VAC/DC
Capacitance: ≤100 pF/m
Temperature Range: -40°C to +85°C (-40°F to +185°F)
end Radius: ≥10x cable

Aero GT Vibration I/O Module

Supply Voltage: 24V DC (±10%)
Power Consumption: <15W (typical)
Input Channels:2 independent channels
Signal Range:±10V (IEPE), 4–20mA (Velocity)
Sampling Rate:Up to 100 kHz per channel
Frequency Response:0.5 Hz – 20 kHz (±3dB)
Dynamic Range:100 dB (typical)
ADC Resolution:24-bit
Analog Output:4–20mA

3500 SYSTEM CHASSIS RACK

02 12-inch Mini-Rack (7 module slots)
04 Panel Mount Option, Mini-Rack
00 None
00 None
01 CE
Mini-rack. 12-inch rack
with seven available module slots

Power Supply Module

0 2 190-250 Vac 50/60 Hz
2 2 Internal Safety Barrier
0 0 Not Required

Low Voltage DC PIM

114M5335-01 Low Voltage DC PIM
Input Voltage:10-30V DC
Input Signal:LVDT/RVDT (1-5V RMS, 2.5-10kHz)
Output Signal:4-20mA (fault = 3.8mA or 21mA)
Accuracy:±0.25% FS

Wind Turbine Monitor

Input Power:24V DC (±10%) or 100–240V AC
Power Consumption:<20W (typical)
Analog Inputs:4–20mA, ±10V, IEPE (2-wire)
Relay Outputs:4x SPDT (5A @ 250V AC)
Communication:Ethernet, Modbus TCP/RTU

3300 XL 8 mm Probe

3300 XL 8 mm Probe
M10 x 1 thread, witharmor
5 0 5.0 metres (16.4 feet)
0 2 Miniature coaxial ClickLocTMconnector
standard cable
0 0 Not required

3300 XL 8 mm Proximity Probes

330101  3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Minimum unthreaded length: 1.5 in
Minimum case length: 4.0in
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

3300 XL 8 mm Proximity Probes

330101  3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Minimum unthreaded length: 5.5 in
Minimum case length: 7.5 in
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

3300 XL 8 mm Proximity Probes

330101  3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Minimum unthreaded length: 0.5 in
Minimum case length: 3.0 in
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

3300 XL 50 mm Proximity Probe

0 2 M14x1.5 Thread
1 0 1.0 meter (3.3 feet)
0 1High Temperature FluidLocCable with Armor
0 0 No Approvals
Proximitor Sensor Material:A380 aluminum

3300 5mm Proximity Probes

330171 3300 5mm Probe
1/4-28 UNFthread, without armor 32 = 3.2 in
0 5 0.5 meter (1.6 feet)
0 1 Miniature coaxial ClickLocconnector
with connectorprotector, standard cable
0 5 Multiple Approvals
