Bently Nevada

Thermocouple Heat Sensor Cable

Thermocouple Type:Type J, K, T, or other
Voltage Rating:300V AC/DC (typical)
Conductor Gauge:20 AWG to 24 AWG
Jacket Material:High-temp PVC

Recip Rod Position Monitor

Signal :Accepts from 1 to 4 proximityprobe signals
InputImpedance:10 kΩ
Peak-Peak filter Fixed:1 Hz to 600 Hz
Gap filter: -3 dB at 0.09 Hz
Average pistonposition Fixed:1 Hz to 600 Hz
Average Gap:-3 dB at 0.09 Hz

System Rack

Full-size rack
01 19-inch Rack (14 module slots)
00 None
00 None
01 CE

3300 XL 25 mm Proximity Probe

02 M30x2 thread
MinimumUnthreadedLength0 mm
MinimumUnthreadedLength 70 mm
90 9.0 metres (29.5 feet)
00 No Armor
05 Multiple Approvals

Proximitor Sensor

3300 XL NSv Proximitor Sensor
71 7.0 meters (23.0 feet) systemlength
DIN mount
00 Not required

VibrationMonitors

DC Input 18~36 Vdc, max 7.5 W
Configurable Bandpass filter 0.2 Hz to 20 kHz
Scale Factorrange 5 to 1000 mV/g
Full scale range 2 to 80 g peak
Current Sink Source 3.3 mA ± 5%
Open Circuit Voltage -21 to -24 Vdc

3300 XL 8 mm Proximity Probes

330104 3300 XL 8 mm Probe
M10 x 1 thread,with armor
Minimum unthreaded length: 80 mm
Minimum case length: 140 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

3300 XL 8 mm Proximity Probes

330104   3300 XL 8 mm Probe
M10 x 1 thread,with armor
Minimum unthreaded length: 0 mm
Minimum case length: 50 mm
05 0.5 meter (1.6 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

Fan monitor

Frequency Range:10 Hz to 1 kHz
Alarm Outputs:2x programmable
Accuracy:±1% of full scale
Power Supply:90-250V AC
Power Consumption:≤15W
Output Signals:4-20mA
Isolation:1500V AC input/output

3300 XL 8 mm Proximity Probes

330104 3300 XL 8 mm Probe
M10 x 1 thread,with armor
Minimum unthreaded length: 80 mm
Minimum case length: 160 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

3300 XL Standard Extension Cable

070 7.0 meters (22.9 feet)
00 Standard cable
05 CSA, ATEX, IECEx  Approvals

3300 XL Standard Extension Cable

045 4.5 meters (14.8 feet)
03 Armored cable with connectorprotector
00 Not required
3300 XL Standard Extension Cable

Velomitor XA Piezo-Velocity Sensor

0 1 CSA/NRTL/C
Velomitor XA Piezo-velocitySensor
330525 Velomitor XA Piezo-velocitySensor

Interconnect Cable

16710-14
Interconnect Cable
3-conductor

3300 XL 11 mm Proximitor Sensor

51 5.0 meter (16.4 feet) systemlength
DIN mount
00 Not required

Velomitor XA Piezo-Velocity Sensor

Sensitivity:3.94mV/mm/s (100 mV/in/s)±5%
VelocityRange:1270 mm/s (50 in/s) peak
Transverse Sensitivity:Less than 5% of sensitivity
Amplitude Linearity:±2% to 152 mm/s (6 in/s) peak
MountingTorque:45 N-m (33 ft-lb) maximum

Proximitor/Seismic I/O Module

Radial Vibration
Thrust Position
Differential Expansion
Shaft Absolute
Eccentricity
Acceleration
Velocity

Accelerometers

02 ¼-28 to M8 x 1.25 Stainless Steel
00 No Approvals
Broadband ElectricalNoise:350 µg
Output Bias Voltage: 8 to 12 VDC
Excitation Voltage:18 to 28 VDC
Constant CurrentExcitation: 2 to 20 mA

Interconnect Cable

Coaxial, shielded
300 V AC/DC
10 feet (3.05 meters)
9-pin D-subminiature (D-Sub)
male connectors at both ends

Interconnect Cable

3-conductor shielded
22 AWG (0.5mm2) armored cable
with 3-socket plug at one end
terminallugs at the other end
Minimumlength of 3.0 ft (0.9 m)
maximumlength of 99 ft (30 m)

Vibration Transmitter

05 0-5 mils pp (0-125 μm pp)
50 5.0 meters (16.4 feet)
70 7.0 meters (23.0 feet)
01 35 mm DIN rail clips
00 Not required

I/O Module

135489-03
BARRIER SEISMIC I/O MODULE
4 CHANNELS
50MA
3500 SERIES
RELAY CONTACTS 5AMP MAX
250VAC MAX
TMR RELAY 2AMP MAX
30V MAXI.S.CIRCUITS

I/O Module

I/O Module with
Internal Barriers
internal terminations
4 x Prox/Accel

3300 NSv Reverse Mount Probe

330906-02-12-CC-DD-EE 3/8-24 UNF threads
05 0.5 meter (20 in)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

Process Variable Monitor

+/-10 Vdc I/O : -10 Vdc to +10 Vdc
4-20 mA Barrier I/O:4-20 mA DC
Voltage Compliance:13.66 V
Isolation:500 Volts
Power Consumption:7.0 Watts, typical
Accuracy:Within ±0.33% of full-scaletypical, ±1% maximum
