ALL MANUFACTURERS

CONTROL UNIT

ACH580
CCU-24-H+N2000 AHVK4.
ACH580 drive systems
Temperature: -20°C to +55°C (full function)
Humidity: 5–95% non-condensing

Safety functions module

Supply Voltage: 20–29 VDC
Power Consumption: 8 W (max)
Response Time: ≤15 ms
Isolation: 2500 VAC
Operating Temperature: -25°C to +60°C

CHARGING CONTROL BOARD

AC Input: 380–480 VAC
DC Input:500–750 VDC
Output Charging Voltage: 24/48/110 VDC
Range: 10–50 A
Current Accuracy: ±1%
Efficiency: ≥92% under full load
Full performance: -10°C to +50°C
Humidity: ≤95% RH (non-condensing)

CONTROL UNIT

ACH580 HVAC Drives
ACH580-31-CCU-24-H+N2000-AHVK4
I/O Expansion:24 VDC
Power Supply:±5% 24 VDC tolerance
Temperature Range: -15°C to +50°C (non-condensing).
Humidity: ≤95% RH.

GATE DRIVER BOARD

3AXD50000049025
GATE DRIVER BOARD
BGDR-01C
MODEL: ACS880-04
4 X CONNECTORS
REPLACED PART# 3AUA0000074145

CONTROL UNIT

CPU BOARD
CCU-24
FOR ACS580 SERIES
ACS580-CCU-24-S+N2000-ASCK4

Control Board

Remote Keypad Mount Kit
Interface Option
Keypad Power Supply:24 VDC
Max Cable Length: ≤ 10 m
Operating Temperature: -25°C to +55°C
Humidity: ≤ 95% RH

CHARGING CONTROL BOARD

RS-485 or CAN Bus
Modbus RTU/TCP compatibility
Overvoltage/Undervoltage Protection
Overcurrent Protection
Short-Circuit Protection
Temperature Monitoring with automatic derating

Capacitor module

TSE capacitor module
C98043-A7017-L1

FPI BOARD

FPI BOARD
G120L Series
Inverter FPI Module Accessories
Voltage Support:380–480V AC
Operating Temperature: 0°C to +40°C

Filter Board

PLC BOARD
FILTER ABSORBER
Up to 24V DC/230V AC
30+ MHz noise frequencies
Leakage Current: Typ. ≤2 mA

Communication components

A5E00242932
SIMATIC S7-300
PROFIBUS DP/MPI
PROFIBUS D-Sub 9-pin
Up to 12 Mbps for PROFIBUS

AC/DC DRIVE MODULE

AC/DC DRIVE
SIMOVERT MASTERDRIVES
890-930 V DC INPUT
660-690 V AC OUTPUT
3 PH
23 KW
1200 AMP
IP00

INTERFACE BOARD

INTERFACE BOARD
TERMINAL BLOCK SE300
FOR TECHNOLOGY MODULE T300
SIMOVERT MASTERDRIVES

Trigger Driver Board

PC BOARD
SINAMICS PM240
Trigger Driver Board

TRIGGER BOARD

260A TRIGGER BOARD
DRIVER BOARD
480 V / 650 VDC / 260 A

Double Motor Module

SINAMICS S120
Double Motor Module
input: 600 V DC
output: 400V 3AC, 18 A/18 A
design: booksize D type
internal air cooling optimized pulse patterns
and support of the extended Safety Integrated
functions incl. DRIVE-CLiQ cable

Control Interface Board

MICROMASTER 430 PX
replacement Control Interface Board
for 380-480 V 3AC
50/60 Hz, 380 A AC Drive

C98043-A1601-L4 Power Board

POWER MODULE
GATING + SV
SIMOREG
(C98043-A1601-L4)

Inverter driver board

SINAMICS S120/S150
Logic-side (control): 24 V DC
Power-side (IGBT control):up to 800 V DC peak
Signal Isolation: ≥2500 V AC
Operating: 0°C to +55°C
Storage: -40°C to +85°C

BRAKING RESISTOR

BRAKING RESISTOR
SINAMICS
160 OHM
4 KW
460 V
FOR POWER MODULE
FSB BASE MOUNTING POSSIBLE

43'' FHD Monitor

Light and cost-effective plastic housing
suitable for continuous 24/7 operation
178°H/178°V extra-wide viewing angle
High fidelity digital processing
8ms fast response time
Support multiple signal inputs
such as HDMI, VGA and USB
Physical button
infrared remote dual control mode

SINGLE MOTOR MODULE

SINAMICS S120
SINGLE MOTOR MODULE
INPUT: DC 600V
OUTPUT: 3-PH 400V, 9A
FRAME SIZE: BOOKSIZE D-TYPE
INTERNAL AIR COOLING OPTIMIZED PULSE
SAMPLE AND SUPPORT OF THE EXTENDED
SAFETY INTEGRATED FUNCTIONS
INCL. DRIVE-CLIQ CABLE

Velomitor CT Transducer

0 1 Stud 3/8-in 24 to 3/8-in 24
0 0 MIL-C-5015 connection interface
0 1 through CSA/NRTL/C (Class I, Division 1)
ATEX/IECEx/CSA (Class I, Zone0/1)

Interconnect cable

Two-conductor 18 AWGtwisted, shielded cable
withright angle two-socket plugat one end
terminal lugs atthe other end.
Used withmonitors and with 21128Velocity
Transducer Housing
Min. length: 2.0 ft (0.6 m)
Max. length: 99 ft (30 m)
