DC Power Supplies

Universal AC Power
High Voltage DC Power Supply
Low Voltage DC Power Supply
Inputvoltage 20 to 30 Vdc
Highvoltage DC 2.5 A (maximum)
Operatingtemperature-30 °C to +65 °C-22 °F to +150 °F
Storagetemperature-40 °C to +85 °C-40 °F to +185 °F
Humidity 95%, non-condensing

Micronet Ethernet Module

Series: MicroNet Digital Controllers
Flash Memory: 64 MB
Input Voltage: 110 VAC/125 VDC
Features: 10/100 Base T Ethernet
Maximum Stub Length: 300 mm
Dimensions: 9.50 x 10.50 x 1.00
Model: 10BaseT Ethernet Connector
Potential Voltage Range: 80-150

Central processing unit

SIMATIC S7-1500
CPU 1517-3 PN/DP
Central processing unit
with work memory2 MB for
Program and 8 MB for data
1st interface: PROFINET IRT with 2-portswitch
2nd interface: PROFINET RT
3rd interface: PROFIBUS
2 ns bitperformance
SIMATIC Memory Card required

System bundle

SIMATIC S7-400H
412-5H system bundle H-system
with 1 x UR2-H, withoutmemory card
2 x PS407 UC120/230V
10 A, 4 x sync modules up to 10 m
2 xsync cables 1 m
2 x CPU 412-5H
in addition 2 memory cards and
4 backupbatteries required

Micro Memory Card

SIMATIC S7
Micro Memory Card
for S7-300/C7/ET 200
3, 3V Nflash
64 KB

Board

4 x 0-10V or 4-20mA inputs
High precision A/D conversion
for accurate measurements of pressure
flow, and other hydraulic parameters
4 x 0-10V or 4-20mA outputs
Sampling Rate: 1 kHz
Resolution: 12-bit or 16-bit resolution for analog I/O
Precision: ±0.1% full scale

Switching Power Supplies

Product: Switching Supplies
Output Voltage-Channel 1: 5 VDC
Output Voltage-Channel 2: -
Number of Outputs: 1 Output
Output Power: 40 W
Open Frame/Enclosed: Open Frame
Input Voltage: 90 VAC to 264 VAC
Output Current-Channel 1: 8 A
Efficiency: 70 %

INTERFACE CARD

4 x 0-10V or 4-20mA inputs
High precision A/D conversion
for accurate measurements of pressure
flow, and other hydraulic parameters
4 x 0-10V or 4-20mA outputs
Sampling Rate: 1 kHz
Resolution: 12-bit or 16-bit resolution for analog I/O
Precision: ±0.1% full scale

Termination assembly

32 channel
voltage monitor132 V AC or 150 V DC
maximumLogic Zero - 0 to 20 V AC; 0to 20 V DC
Logic One - 80 to 132 V AC;75 to 150 V DC
Input Current for Logic One;2.6 mA
maximumChannel isolation provided by
termination assembly

TERMINATION ASSEMBLY

VOLTAGE MONITOR TERMINATION ASSEMBLY
SCREW TERMINAL
EXTERNAL SWITCH
CABLE TYPE 4
FBM 241 125V
VMON, +5A
RELAY OUT
P/N - P0916AS

System Rack

01 19-inch Rack (14 module slots)
02 Rack Mount Option, Full-Size Rack
(mounts to19-inch EIA Rack)
01 CSA/NRTL/C (Class 1, Division 2)
00 None
01 CE
The 3500/05 mini-rack is not available
in theBulkhead Mount option.

Temperature Monitor

Accepts from 1 to 16 signals
Input impedance: Greater than 1 MΩ
Power consumption: 3 watts
Front panel LEDs: OK, TX/RX, Bypass
Type E, J, K, T thermocouples
100 Ω 3-wire and 4-wire platinum RTD

Analog Input/Output Module

8 channels AIO208, 16 channels AIO216
Analog inputs and outputs
Filter adjustable from 4 kHz to 0.5 Hz per channel
All outputs overload, short circuit and external voltage-proof
Measuring range monitoring freely adjustable (±105 %)
Error message on overload and overtemperature and undervoltage of the supply
Galvanic isolation from the system 500 V
Modes that can be selected per channel:
Analog voltage input ±10 V to ±10 mV
Analog current input 0(4) to 20 mA

Protection System

Monitoring of Sensors
Monitoring versus Low speed as
protection versus incorrect mounting
or fault of speedsensors.
Monitoring versus overspeed

4-Channel Relay Module

PowerConsumption 5.8 Watts typical
EnvironmentalSealing Epoxy-sealed
Arc Suppressor 250 Vrms, installed asstandard
Contact Life 100,000 cycles @ 5 A, 24 Vdcor 240 Vac
OperatingTemperature-30°C to +65°C(-22°F to +150°F)
StorageTemperature-40°C to +85°C(-40°F to +185°F)
Humidity 95%, non-condensing
Minimum switchedcurrent 100 mA @ 12 Vdc

System Display

Local or Remote Visual Indication
of 3500 Machinery Protection System
(4) Display Mounting Types
Up to (2) Displays per 3500 Rack
Input Signal: -10 Vdc to +10 Vdc
Power Consumption: 10.5 watts
Product Type: System Display Interface I/O Module
Ethernet: 100Base-FX Fiber-Optic
Operating Temperature -30°C to +65°C (-22°F to+150°F)

Rack Interface Module

PowerConsumption 4.75 watts, typical
Standard RS232 serial communications
Data Rate 38.4 k baud.
RS232 30 metres (100 feet) maximum
RS422 1200 metres
Communications Hayes AT-compatible
Baud Rate 14.4 k baud maximum
OperatingTemperature -30°C to +65°C

Proximitor Monitor

Signal Accepts from
1 to 4 proximitytransducer signals
Powerconsumption 7.7 Watts, typical
Standard I/O10 kΩ
Gap filter -3 dB at 0.09 Hz
Smax 0.125 to 15.8 times runningspeed
Direct filterUser-programmable
Single-pole4 Hz to 4000 Hz or1 Hz to 600 Hz

VGA Display Monitor

Powerconsumption 4.6 watts max.
High-speednetworkMonitor status, data andvalues
RS232 port(I/0) Touch controller data
OK LED Indicates proper operation ofthe module
TX/RX LEDIndicates
communicationsbetween other systemmodules
VGA port(I/O)Analog red, green,
blue andsync signals to the display
Front Port 24 Vdc Power out,
VGA signalout, Touch commands in.

Proximitor Monitoris

Signal Accepts from
1 to 4 proximitytransducer signals
Powerconsumption 7.7 Watts, typical
Standard I/O10 kΩ
Impedance 550 Ω
TransducerPowerSupply-24 Vdc
Gap filter -3 dB at 0.09 Hz
Direct filter -3 dB at 1.2 Hz

Vibration Transmitter

7 0 7.0 metres (23.0 feet)
0 2 Bulkhead screws
0 1 CSA Division 2
Power : Requires +12 to +35 Vdc
input at the transmitter terminal.
Maximum Loop Resistance :
1,000 Ω including cable at 35 Vdc.
Current Limiting : 23 mA typical.

Vibration Transmitter

7 0 7.0 metres (23.0 feet)
0 1 35 mm DIN rail clips
0 1 CSA Division 2
Power : Requires +12 to +35 Vdc
input at the transmitter terminal.
Maximum Loop Resistance :
1,000 Ω including cable at 35 Vdc.
Current Limiting : 23 mA typical

Vibration Transmitter

5 0 5.0 metres (16.4 feet)
0 2 Bulkhead screws
0 1 CSA Division 2
Power : Requires +12 to +35 Vdc
input at the transmitter terminal.
Maximum Loop Resistance :
1,000 Ω including cable at 35 Vdc.
Current Limiting : 23 mA typical.

Vibration Transmitter

5 0 5.0 metres (16.4 feet)
0 2 Bulkhead screws
0 0 Not required
Power : Requires +12 to +35 Vdc
input at the transmitter terminal.
Maximum Loop Resistance :
1,000 Ω including cable at 35 Vdc.
Current Limiting : 23 mA typical.

Vibration Transmitter

5 0 5.0 metres (16.4 feet)
0 1 35 mm DIN rail clips
0 5 CSA Division 2, ATEX Zone 0,
ATEXZone 2 and includes ABS maritimeapprova
Power : Requires +12 to +35 Vdc
input at the transmitter terminal.
Maximum Loop Resistance :
1,000 Ω including cable at 35 Vdc.
Current Limiting : 23 mA typical.
