Number of Digital Configurable I/Os: 24
Input Voltage Type:DC
Input Current:5 mA
Maximum Input Voltage:0 ... 30 V
Delay Time (τ):0.1 … 32 ms
Output:Transistor
Output Voltage Type:DC
Output Voltage (Uout):24 V DC
Output Current:0.5 A
Output Voltage Maximum:20.4 … 28.8 V
SSTSR4CLXRLLCC
(1120780002) SST SERIAL IN CHASSIS MODULE
FOR ROCKWELL AUTOMATION CONTROLLOGIX
SERIAL MODBUS RTU/ASCII MASTER/SLAVE
4 CHANNELS
CONFORMAL COATED
Brand:GE Fanuc
Series:Genius I-O
Part Number:IC660EBA023
Application:Genius I/O Block System
Operating Voltage:18 to 56 Volts DC
Group Isolation:300 Volts
Power Rating:9.0 Watts
LEDs:2 LEDs
Built-in Diagnostics:Yes
Series:Genius I-O
Manufacturer:GE Fanuc / Emerson Automation
Part Number:IC660EBA024
Series:Block I/O
Description:Genius I/O Block Electronic Assembly
Part Number:IC660EBA024
Application:Genius I/O Block System
Product Description:Electronics Assembly
Operating Voltage:18 to 56 Volts DC
Power Rating:12.0 Watts
Compatible Terminal base:IC660TBA024
Input Type:4 Isolated Source-Type Inputs
Nominal Operating voltage:24 / 48 VDC
Output Type:2 Analog Outputs
Supply voltage range:18-56 VDC
Input Signal Range:4 to 24 Milliamps
Block to Block isolation:1500 V for 1 minute
Channel to Channel Isolation:1500 Volts RMS
Group to group isolation:300V rms
LED:2 LEDs
Temperature monitoring is available in 16 channels.
Temperature inputs can be RTD or TC
Accepts isolated tip thermocouples,
3-wire or 4-wire RTDs
or a combination of
TC and RTD inputs
IC697PWR711
DISCONTINUED BY MANUFACTURER
POWER SUPPLY MODULE
110/220 VAC OR 115 VDC
50/60 HZ
5 VDC OR +/-12 VDC OUTPUT
1.6/3.5/21 AMPS OUTPUT
100 WATTS MAXIMUM
Tariff Code: 8504409530
Country of Origin: United States
Communications processor
CP 343-1 Lean for connection of
SIMATIC S7-300 to Industrial
Ethernet via TCP/IP and UDP
Multicast, SEND/RECEIVE with
and without RFC1006, Fetch/ Write
S7 communication (server)
PROFINET IO device integrated 2-port
switch ERTEC 200, Module
replacement without PG, SNMP diagnostics
initialization via LAN
2x RJ45 connection for
LAN with 10/100 Mbit/s
Model: FI820F
Product Line: AC800F
Supports DP-V0 and DP-V1
Voltage: 24 V DC (±20%)
Current Consumption: 100–150 mA
Operating Temperature:
-25°C to +60°C (-13°F to +140°F)
Storage Temperature:
-40°C to +85°C (-40°F to +185°F)
Relative Humidity: 5–95% (non-condensing)
SINAMICS/MICROMASTER
PX spare power supply
380-480 V 3AC, 50/60 Hz
AC Drive/Power/Motor Module
for repair order spare part
defective part for credit voucher
3300 XL 8 mm Probe
M10 x 1 thread
without armor
10 1.0 meter (3.3 feet)
01Miniature coaxial ClickLocconnector
with connectorprotector, standard cable
00 Not required
3300 XL 8 mm Probe
M10 x 1 thread,without armor
10 1.0 meter (3.3 feet)
01Miniature coaxial ClickLocconnector
with connectorprotector, standard cable
00 Not required
Number of input channels: 24
Input Filter: Hardware filter, 4 ms
Input Signal Logic: Active High / Active Low
Input isolation in pack: 1500 V
Input Voltage Range: 5V DC / 24V DC
Ac voltage rejection: 60 V RMS
Isolation: Optical or Galvanic Isolation
Output Voltage Range: 5V DC – 250V AC
Contact Rating (Relay Output): 5A
330709 3300 XL 11 mm Probe
M16 x 1.5 thread,without armor
Minimum length:50 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required
330101 3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Minimum unthreaded length: 1.0 in
Maximum case length: 2.7 in
05 0.5 meter (1.6 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx Approvals
469P5HIA20EH
DISCONTINUED BY MANUFACTURER
MOTOR MANAGEMENT RELAY
BASE UNIT 469
CURRENT TRANSFORMER INPUTS - 5 AMP
90-300 V DC
70-265 V AC
48/62 HZ
4-20 MA ANALOG OUTPUTS
ENHANCED FRONT PANEL
HARSH CONFORMAL COATING
Linear Measurement Range:2 mm (80 mils)
Initial Air Gap:0.5 mm (20 mils)
Incremental Scale Factor
ISO: 8 V/mm (203.2 mV/mil)
± 5%@ temperature range 0 to 45°C(+32 to +113°F)
Deviation from best fit straight line
± 0.025 mm (± 1 mil)@
emperature range 0 to 45°C(+32 to +113°F)
Minimum Shaft Diameter:25 mm (0.79”)
Communications processor CP 343-1
for connection of SIMATIC S7-300
toIndustrial Ethernet via ISO and TCP/IP
PROFINET IO controller or PROFINET IOdevice
integrated 2-port switch ERTEC 200
S7 communication, fetch/write
SEND/RECEIVE RFC1006, multicast, DHCP
NTC- CPU sync, with and withoutdiagnostics
initialization via LAN,
2x RJ45 connection for LAN with 10/100 Mbit/s
S7-300 CPU
313C-2 DP COMPACT CPU W
MPI
16 DE/DA
16 3 FAST COUNTER (30 KHZ)
INTEGRATED DP INTERFACE
POWER SUPPLY 24 VDC
FRONT CONNECTOR (1 X 40-PIN)
MEMORY CARD REQUIRED
350093
DISCONTINUED BY MANUFACTURER
DISPLAY INTERFACE I/O MODULE
15.5 W MAX
-20C TO 65 DEGREE C W/ DISPLAY COMMUNICATIONS PORT
PWA 135799-01
Tariff Code: 8517620050
Country of Origin: United States
