We offer comprehensive SIEMENS automation technologies, specializing in the supply of core systems including:
SIMATIC S7 Series,SIMATIC S5,Siemens Moore,6DD/6DP Series,MICROMASTER & SINAMICS,OP/MP/TP Series HMIs
Whether you require components for specific platforms or need to source replacement/obsolete parts based on equipment functionality Call me now: +86 18020776786.
We are committed to sourcing mission-critical SIEMENS products you require.
We offer comprehensive SIEMENS automation technologies, specializing in the supply of core systems including:
SIMATIC S7 Series,SIMATIC S5,Siemens Moore,6DD/6DP Series,MICROMASTER & SINAMICS,OP/MP/TP Series HMIs
Whether you require components for specific platforms or need to source replacement/obsolete parts based on equipment functionality Call me now: +86 18020776786.
We are committed to sourcing mission-critical SIEMENS products you require.
SIMATIC S7-200 SMART
Analog output SM AQ04
4 AO, +/-10 V, 11 bitresolution
or 4-20 mA, 11 bit resolution
Rated value (DC) 24 V
permissible range, lower limit (DC) 20.4 V
permissible range, upper limit (DC) 28.8 V
Current consumption, max. 103 mA
from backplane bus 5 V DC, max. 61 mA
Power loss, typ. 2.7 W
Field Device Coupler
FDC 157 physical interface
for PROFIBUS PA or Foundatio
Fieldbus H1 integrated bus supply up to 1000 mA
with redundancy capabilityintegrated
diagnostics Degree of protection
IP20 for extended temperature range
SIMATIC DP
INTERFACE MODULE IM151-1STANDARD
FOR ET200S; TRANSMISS
RATE UP TO 12MBIT/S
DATA VOLUME 128BYTE FOR
EACH INPUT AND OUTPUT
MAX.OF 63 POWER, ELECTR
OR MOTOR STARTER MODULES
UPTO 2M WIDTH CONNECTABLE
BUS INTERFACING VIA 9-WAYSUB-D
INCL. TERMINATING MODULE
SIMATIC S7
ANALOG INPUT SM336
6 AI; 14BIT; 40 PIN
FAILSAFE ANALOG INPUTS FOR
SIMATIC S7FSYSTEMS
WITH DIAGNOST. INTERRUPT
Rated value (DC):24 V
power supply L+, typ.:160 mA
backplane bus 5 V DC, max:90 mA
Power loss, typ:4.25 W
SIMATIC DP
INTERFACE MODULE IM151-1
STANDARD FOR ET200S
TRANSMISS. RATE UP TO 12MBIT/S
DATA VOLUME 128BYTE FOR
EACH INPUT ANDOUTPUT
MAX. OF 63 POWER,ELECTR
OR MOTOR STARTER MODULESCONNECTABLE
BUS INTERFACING VIA 9-WAY SUB-D CONN
INCL.TERMINATING MODULE
SINAMICS S120
SINGLE MOTOR MODULE
INPUT: DC 600V
OUTPUT: 3AC 400V, 200A
OUTPUT: at 8 kHz / 140A
FRAME SIZE: BOOKSIZE
INTERNAL AIR COOLING OPTIMIZED
PULSE SAMPLE AND SUPPORT OF
THE EXTENDED SAFETY INTEGRATED FUNCTIONS
INCL. DRIVE-CLIQ CABLE
